Innovative Reuse of Concrete Components Gaining Momentum in Construction

📅 Today

The construction industry is increasingly focusing on the recycling and reuse of concrete components, with projects in Europe demonstrating significant sustainability benefits. Notable examples include the reuse of concrete slab walls for paving in France and the innovative Re:Crete footbridge in Switzerland.

The practice of recycling and repurposing components from demolished buildings, including windows, doors, and structural elements, has gained traction in the construction sector. These materials can be effectively utilized in new construction projects. Concrete components, such as walls, floors, beams, and posts, are typically reprocessed into base materials. When these concrete pieces are crushed into recycled concrete aggregate, they provide a highly stable and cost-efficient alternative to traditional virgin gravel or stone for the construction industry.
In Europe, recent experimentation and studies have explored alternative futures for large precast or poured concrete building elements. Instead of grinding these materials down, it’s possible to cut them and repurpose them for new projects. A notable example of this approach took place in the Île-de-France region of northern France, where HABITAT 77, a provider of diverse social housing options, successfully reused concrete slab walls from a former parking garage. These slabs were transformed into a 470 m² (5,059 square feet) paving surface for a nearby project. The process involved two main steps: first, the slabs were cut from the parking structure, and then they were assembled like flagstone to create the intended surface area. Each slab was cut into manageable squares weighing approximately 300 kilograms and measuring between 15 and 20 centimeters thick. Project co-ordinator Hugo Topalov highlighted the importance of finding an optimal size for the slabs to balance cutting costs and ease of handling.
Another significant demonstration of concrete reuse was the Re:Crete Footbridge, which spans the Morge River in Switzerland. This initiative, spearheaded by researchers from the Swiss Federal Institute of Technology Lausanne (EPFL), showcased the feasibility of reusing concrete elements extracted from an existing cast-in-place structure for a new load-bearing application. The project resulted in a 10-meter segmented arched footbridge constructed from 20-centimeter-thick concrete blocks, which were saw-cut from the walls of a building undergoing renovation. The construction involved drilling 25 blocks to accommodate post-tensioning cables and assembling them on a timber centering to facilitate the threading of the cables. The exposed cut rebar was treated with anti-corrosion paint, while hydrophobic impregnation was applied to the concrete faces, and waterproofing strips were used to cover the joints.
From an environmental perspective, the Re:Crete footbridge significantly reduced the carbon footprint compared to traditional construction methods. A detailed life cycle analysis indicated a reduction in environmental impact of 63% compared to new reinforced concrete and 75% compared to steel, while still being only nine percent more expensive than an entirely new wooden bridge. The project has received several accolades, including Construction21 Network’s Infrastructure Users’ Choice Prize and the Sustainable Infrastructure Grand Prize at the national level of the Green Solutions Awards 2022-2023.
Despite the growing interest in reusing construction materials, scaling these practices, particularly with concrete, remains a challenge. While recycled concrete is integrated into supply chains for backfill and road sub-bases, current practices often hinder the development of reuse strategies. Ademe, a public agency under the joint authority of France’s Ministry for the Environment, has convened a group of 80 European stakeholders to investigate the feasibility of concrete reuse operations. They have supported six pilot projects, including a research initiative in north central France focused on the reuse of load-bearing columns and beams.
The ReCrete project findings revealed that deconstruction could be up to twice as costly as traditional demolition, even if the subsequent reuse of components proves more economical than using new materials. Insurers have expressed concerns regarding structural integrity, leading to the abandonment of several projects when suitable coverage could not be secured. Karine Niego, an innovation and ecological transition consultant at YesWeGreen, emphasized that overcoming organizational and structural barriers is crucial for the successful implementation of concrete reuse. She stated, "Today, our processes follow a simple logic: demolish, treat waste, rebuild. The entire chain is conceived this way. However, reuse requires moving beyond this."
To date, fewer than 100 concrete reuse projects have been undertaken, primarily in Europe. The lack of concrete component resellers exacerbates this issue, according to Célia Küpfer, an architect and professor at McGill University’s Peter Guo-hua Fu School of Architecture. She suggested that if the interdependence between donor and recipient sites could be addressed, the dismantling process could occur independently of target projects. As more successful examples and studies of concrete reuse emerge, there is hope for increased acceptance and implementation of these practices in the near future.
